NEW SUPREME
Suitable for under Area Rugs for premium cushioning.
Excellent Sound Insulation @39dB Impact Sound Reduction.
Prolongs the life of carpets.
Roll Size: 1.37 m x 8 m
Roll Area: 10.96 m²
Manufactured In U.K.
Test Results to BS 5808 : 1991-British Standard for Carpet Underlays | ||||
Specification | BS Requirements | Result | Method | |
Material Composition | 100% Sponge Rubber | |||
Total Weight | Ca. 3424 g/m² (101 oz/yd²) | |||
Total Thickness | Ca. 8.75 mm (0.34″) | ISO 1765 | ||
Density | Ca. 391 kg/m³ (24.41 bs/ft³) | |||
Roll Area | Ca. 10.96 m² | |||
Roll Size | 1.37 m x 8 m | |||
End Use Classification | L/U, Luxury Use | BS 5808:1991 | ||
Work of Compression | Min. 50 J/m² Max. 200 J/m² after dynamic loading for 1000 impacts | 143 J/m² | BS 4908 & BS 4052 & ISO 2094 | |
Retention of Work of Compression | Min 40% of original after 1000 impacts | 88% | BS 4908 & BS 4052 & ISO 2094 | |
Resistance to Cracking | not greater than 50mm | Pass | EN 14499 & BS 5808 | |
Loss in Thickness after Dynamic Loading | Max. 15% after 1000 impacts | 4% | BS 4052 & ISO 2094 | |
Loss in Thickness after Static Loading | Max. 15% after 24 hours recovery | 3% | ISO 3415 / 3416 & BS 4939 | |
Flammability | Result | Method | ||
Hot Metal Nut Test | Pass – Low radius of effects of ignition | BS 4790 & BS 5287 | ||
US Methenamine Pill Test | Pass | DOC-FF 1-70 | ||
Russian GOST FR Test | Classification KM5 | GOST 30244-94, GOST 30402-96, GOST 51032-97, GOST 12.1.044-89(item 4.18), GOST 12.1.044-89(item 4.20) | ||
Test Performance to US Standards | ||||
CFD (Compression Force Deflection) | 2.2 PSI @ 25% deflection. Method: 601/12151 | ASTM D3676-13 | ||
CFD (Compression Force Deflection) | 6.7 PSI @ 50% deflection. Method: 601/12151 | ASTM D3676-13 | ||
CFD (Compression Force Deflection) | 15.9 PSI @ 65% deflection. Method: 601/12151 | ASTM D3676-13 | ||
Recommended Use | Moderate Traffic Class I | US Carpet Cushion Council | ||
Other Properties and Test Performance | ||||
Odour | No objectionable odour | |||
Colour / backing | Green / printed Textron® backing | |||
Thermal resistance (European Units) | 1.00 togs | BS 4745 | ||
– R value (SI Unit) | 0.08 | |||
– R Value (USA Unit) | 0.45 | |||
Impact Sound Reduction (ΔLᴡ) | 39 dB | BS EN ISO 10140-3:2010 | ||
Emissions (US Carpet & Rug Institute) | Meets Low VOC Emission Criteria (Certified GLP051 Cat CC10 Rubber) | US CRI Green Label Plus Programme | ||
Antimicrobial and mildew resistant | Pass | |||
GREEN CREDENTIALS | ||||
Green Features | Description | LEED Programme | ||
Recyclable | At the end of the underlays useful life, it can be 100% recycled | MR 2.0: Points Available, it can be 100% recycled | ||
Recycled Content | Contains not less than 3% pre-consumer recycled material | MR 4.0: Points Available, Recycled Content | ||
Indoor Air Quality | Meets or exceeds the industry standard for indoor air quality as established by the CRI Green Label Programme | IEQ 4.3: Points Available, Product is Green | ||
Installation | ||||
Subfloors should be dry, clean and free of oil, grease & damp. STRETCH FIT suitability. Fitting should meet the British Standard code of practice BS 5325 & be undertaken by experianced fitters. | ||||
Recommended Use Areas | ||||
Hotel Guest Rooms, Suites, Banquet Hall, Ballroom, Smaller Function Room, Restaurant, Lounge, Bar, Bedrooms, Living Rooms, Throughout Apartments or Private Villas (Except Stairs), under Area Rugs for premium cushioning, and excellent for Sound Insulation. | ||||
Link to Test Report | Certificate | |||
20210817 |
