GRANITO LVT

Description

CLICK VINYL PLANKS | Heritage Click Lock | UV Matt Coating | Stone Visual

Sizes: 600mm x 300mm x 4mm

Usage: Residential, commercial, hospital, schools, kids nursery rooms, etc.

HERITAGE Click Vinyl Flooring series offers a durable wood-like finish with natural textures and realistic details. For a beautiful and versatile floor, choose HERITAGE Click Vinyl Flooring for your home or small business. Go where your inspiration takes you. All pictures shown are for illustration purpose only. Actual product colour may vary due to product enhancement.

Specification


GRANITO LVT Specifications

Dimension (L x W x T)		600 mm x 300 mm x 4 mm
		(24” x 12” x 1/6”)
Surface Material		Virgin PVC
Texture		Stone Visual
Protective Wear Layer Thickness		0.5 mm
Gloss Level		10 (+/- 2)
Surface Finish		UV Matt Coating
Locking System		Heritage Click Lock
Edge Finish		Straight Edge
Packing per carton		12 pieces (2.16 m²)
Carton dimensions		615 mm x 312 mm x 52.4 mm
Weight per piece		1.51 kg
Weight per sqm		8.38 kg
Weight per carton		18.12 kg

Performance

CHARACTERISTIC	EN Norms	RESULT	EN Norms	RESULT
PRODUCT STABILITY
Dimension Squareness	EN 427:1994	Pass: 0.18 mm	ASTM F 2055	Pass: 0.18 mm
Dimension Straightness	EN 427:1994	Pass: 0.07 mm	ASTM F 2055	Pass: 0.07 mm
Overall Dimensional Stability	ISO 23999:2008 / EN 434:1994	Pass: 0.1%	ASTM F 2199	Pass
Curling after Exposure to Heat	ISO 23999:2008 / EN 434:1994	Pass: 0.0 6mm	ASTM F 2199	Pass
Residual Indentation after Static Loading	ISO 24343-1:2007 / EN 433:1994	Pass: 0.06 mm	ASTM F 970	Pass
Plank Flexibility	EN 435:1994 Method A	Pass	ASTM F 2199	Pass
PRODUCT DURABILITY
Resistance to Wear	ISO 24388-A / EN 660-2:1999+A1:2003 / EN 649:2011	Fv: 1.8 mm³. Wear Group: T > 1000 cycles
Resistance to Abrasion	EN 13329:2006 / A1:2008	3000 cycles: Class: > AC3
Resistance to Impact	ASTM F1265:2003a (2008)		ASTM F 1265	Pass
Resistance to Castor Chairs	ISO 4918 / EN 425:2002	No visible damage after 25000 cycles / under 90 kg	ISO 4981 / EN 425:2002
Resistance to Peeling	EN 433:1994	X direction: 5.5N / 50 mm Y direction: 5.5N / 50 mm
Resistance to Chemicals and Stains	ISO 26987 / EN 423:2001	Pass	ASTM F 925:2002	Pass
Resistance to Articial Light (Colorfastness)	EN 20105:B02 Method A	Pass: ≥ Grade 6	ASTM F 1515	Pass
Thermal Resistance	EN 12664:2001	Pass
	EN 12524:2000	0.07 W/m-K
Suitability for Underfloor Heating		Suitable (max. 27˚C)
Water resistance		Yes (Suitable for indoor wet areas)
PRODUCT SAFETY
Fire Test – Flame Spread	EN 13501-1:2007	Pass: Bf1-S1	ASTM E648-06	Pass: Class I
Fire Test – Smoke Evolution (Smoke Density)			ASTM E622	Pass: ≤ 450
Electrical Resistance	EN 1081:1998 Method C	Pass: R₁ > 10¹⁰ Ohm	ASTM F150-06	Pass
Electrical Resistance	EN 1815:1998	Pass: > 2.0 kV on concrete	ASTM F150-06	Pass
Resistance to Slipping	EN 14041:2004/AC:2006 Clause 4.5 / EN 13893:2002 / DIN 51130	Pass: R10 / Class DS	ASTM D2047-93	Pass: 0.1%
ENVIRONMENTAL IMPACT
Toxicity – Pthalates (DBP / BBP / DEHP / DINP / DNOP / DIDP)	EN 14372:2004	Pass
Toxicity – Soluble Heavy Metals	EN 71-3:1994	Pass: Heavy Metals and formaldehyde not detected
Formaldehyde Emission	EN 14041:2004	Pass: E1
Hygiene		Does not contribute to infection spreading
Impact Sound Insulation	ISO 140-8 / ISO 717-2:2013	13dB
VOC Regulations / Indoor Air Quality	ISO 16000-9:2006	Pass	FloorScore®	A+

Test Report	Warranty	Certificate
